EPEVER VS-AU SERIES VS2024AU 12/24V 20A
ViewStar AU controller is a PWM charge controller with built-in LCD display which adopts the most advanced digital technique.
Recipient :
* Required fields
or Cancel
VS1224A
New product
ViewStar AU controller is a PWM charge controller with built-in LCD display which adopts the most advanced digital technique.
This product is no longer in stock
Warning: Last items in stock!
Availability date: 0000-00-00
ViewStar AU controller is a PWM charge controller with built-in LCD display which adopts the most advanced digital technique. The multiple load control modes allow it to be widely used on solar home systems, traffic lights, solar street lights, solar garden lights, etc.
VS-AU Series VS2024AU 12/24V 20A
The VS-AU series is a PWM charge controller with LCD display and two USB ports. When the discrepancy between the solar panel operating voltage and the battery voltage is not large, choosing this PWM series is an equally reliable but more cost-effective solution. It is widely applied to rural electrification and home power systems, etc.
Features
• Series PWM charging mode
• Full power working at working temperature range
• Multiple load control modes
• Adopt high quality, high-reliability international brand components
• Double USB design
• Segment LCD display design
• Real time energy statistics function
• Extensive electronic protection
Technical characteristics
Model | VS2024AU |
Rated system voltage | 12/24VDC Auto |
Battery Type | Sealed (default)/Freeze/Flooded |
Battery input voltage range | 9V~32V |
Rated load current | 20A |
Rated discharge current | 20A |
Max. PV open circuit voltage | 50V |
Equalization voltage | Sealed: 14.6V, Flooded: 14.8V |
Boost voltage | Freeze:14.2V,Sealed:14.4V,Flooded:14.6V |
Float voltage | Freeze/Sealed/Flooded:13.8V |
Low voltage reconnect voltage | Gel/Sealed/Flooded:12.6V |
Low Voltage Disconnect Voltage | Freeze/Sealed/Flooded:11.1V |
Self-consumption | ≤9.2mA/12V;≤11.7mA/24V;≤14.5mA/36V;≤17mA/48V |
USB output | 5VDC/2.4A(Total) |
Temperature compensated | `-3mV/℃/2V(25℃) |
Relative humidity | ≤95%, NC |
Housing | IP30 |
Grounding | Common positive |
Operating temperature range | `-25℃~+55℃ |
Dimensions(LxWxH)(mm) | 160×94.9×49.3 |
Net weight | 0.35kg |
Technical characteristics
Length | 160mm |
Voltage | 12V/24V |
Solar input voltage max. | 9V~32V |
Open circuit voltage (Voc) | 50V |
Width | 94.9mm |
Height | 49.3mm |
Charging current | 20A |
